| Machine Specifications | Smartcut 4032 Ci | Smartcut 5040 Ci | Smartcut 6350 Ci | Smartcut 8063 Ci | Smartcut 4032C | Smartcut 5040C | Smartcut 6350C C | Smartcut 8063C |
|---|---|---|---|---|---|---|---|---|
| X,Y Axis Travel (mm) | 400 x 320 | 500 x 400 | 630 x 500 | 800 x 630 | 400 x 320 | 500 x 400 | 630 x 500 | 800 x 630 |
| Work Table Size (WxD mm) | 600 x 380 | 720 x 460 | 820 x 550 | 1070 x 710 | 600 x 380 | 720 x 460 | 820 x 550 | 1070 x 710 |
| Job Admit (mm) | 330 | 330 | 430 | 430 | 330 | 330 | 430 | 430 |
| Max. Workpiece Weight (Kg) | 450 | 600 | 800 | 1200 | 450 | 330 | 800 | 1200 |
| Max Taper Angle (Deg/mm) | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 | ” +/- 3/100 |
| X,Y LM Guide | YES | YES | YES | YES | YES | YES | YES | YES |
